S-Band Single Patch Antenna

• Frequency Band : 2200-2290MHz
• Peak Gain : 5.7±0.2dBiC
• Half-Power Beamwidth (HPBW) : 102o±6o
• Polarization : Right-Handed Circular (RHCP)
• Axial Ratio : < 5dB within HPBW
• Power Handling : 5W CW Typ
• Mass : 21.5g

S-Band Single Patch Antenna

• Frequency Band : 2025-2110MHz
• Peak Gain : 5.7±0.1dBic
• Half-Power Beamwidth (HPBW) : 90o±2o
• Polarization : Right-Handed Circular (RHCP)
• Axial Ratio : < 4.0dB within HPBW
• Power Handling : 5W CW Typ
• Mass : 24g

S-Band Single Patch Antenna

• Frequency Band : 1980-2110MHz (Rx),2160-2290MHz (Tx)
• Peak Gain : 6.2±0.4dBiC, >1dBiC within ±60o Off-Nadir @Rx
• Half-Power Beamwidth (HPBW) : 93o±4o@Rx, 91o±4o@Tx
• Polarization : Right-Handed Circular (RHCP)
• Axial Ratio : < 3.5dB within HPBW
• Power Handling : 5W CW Typ
• Mass : 49±0.5g

Dual S-Band Patch Antenna

• Frequency Band : Rx@2025-2110MHz, Tx@2200-2290MHz
• Peak Gain : 5.5±0.3dBic @Rx, 6.1±0.2dBic @Tx
• Half-Power Beamwidth (HPBW) : 87o±4o @Rx, 85o±4o @Tx
• Polarization : Right-Handed Circular (RHCP), pre-configurable
• Axial Ratio : < 6dB within HPBW
• Power Handling : > 17dB @Rx, > 33dB @Tx
• Mass : 107g

8x16 Ka-Band Phase Array Antenna

• Antenna Gain : 22dBi
• Beam Width : Narrow 9°- 15°, width 45°- 60°
• Scan Range : ± 20 El, ± 60 Az
• Power consumption : <21 W

X-Band 2 x 2 Patch Antenna Array

• Frequency Band : 8.025-8.4GHz
• Peak Gain : 12.4±0.4dBic
• Half-Power Beamwidth (HPBW) : 34o±1o
• Polarization : Right-Handed Circular (RHCP)
• Axial Ratio : < 3dB within HPBW
• Power Handling : 5W CW Typ.
• Mass : 21.5g, incl. connector & fixings

X-Band 4 x 4 Patch Antenna Array

• Frequency Band : 8025-8400MHz
• Peak Gain : 16.1±0.4dBic
• Half-Power Beamwidth (HPBW) : 17.8o±0.7o
• Polarization : Right-Handed Circular (RHCP)
• Axial Ratio : < 3dB within HPBW
• Power Handling : 5W CW Typ.
• Mass : 54g

X-Band 4 x 8 Patch Antenna Array

• Frequency Band : 8025-8400MHz
• Peak Gain : 19.2±0.3dBic
• Half-Power Beamwidth (HPBW) : 18.5o±0.5o@XZ-Plane, 8.7o±0.3o@YZ-Plane
• Polarization : Right-Handed Circular (RHCP)
• Axial Ratio : < 3dB within HPBW
• Power Handling : 5W CW Typ.
• Mass : 128g

X-Band 8x8 Patch Antenna Array

• Frequency Band : 8025-8400MHz
• Peak Gain : 23.5±0.5dBic
• Half-Power Beamwidth (HPBW) :　8.5o±0.4o
• Polarization : Right-Handed Circular (RHCP)
• Axial Ratio : < 1.0dB within HPBW
• Power Handling : 5W CW Typ.
• Mass : 366g

K/KA Band Communication Payload

Rapidteks communication payload （CPL） enables flexible configuration across various communication protocols through its integration of software-defined radio （SDR）, along with up- and down-converters, a power amplifier, and a low-noise amplifier. Designed for bi-directional communication （Tx and Rx）, the CPL’s operating frequency band can be further tailored to S-band, X-band, Ku-band, or K/Ka-band by adjusting the front-end module.

• Integrated SDR and RF front-end
• Support bi-directional communication (Tx and Rx)
• Frequency band operation adjustable
• With integrated up and down converter, PA and LNA
